Woox Kamera VENZ R4259 2K, 360°, Wireless, WiFi

Hardware Specification

Image Sensor

1/4" 1Megapixel progressive CMOS

Sensor Brand And Model

GC1054

Main Chipset Brand And Model

GK7202V300

Wi-Fi Chipset Brand And Model

8188

Lens Brand And Model

JX6401  3MP

Lens Length

4mm

Aperture

F2.2

Speaker

1W, 8Ω

Noise Reduction

3D

Antenna Gain (dBi)

2DB

Electrical Specification

Power Supply

DC 5V 1A

Power Supply by USB Directly without Battery

No

Working Power Consumption

1.5W

Standby Power Consumption

1.5W

Notification Image Resolution

HD(2304*1296)

Live Stream Video Resolution

HD(2304*1296) / SD(640*360)

Live Stream Effective Pixels

3MP

Live Stream Effective Pixels by HW or SW

SW

Angle of View(H/v/D)

79.5°/43.1°/93.6°

Angle of Pan and Tilt

355°/(down 15°, up of view 50°, up of privacy 70°)

Microphone Sensitive

-38dB

Audio Input

Built in Mic

Audio Output

Built in Speaker

Video Compression

Video: H.265/H.264

Audio Compression

Audio: G.711a/G.722.1/G.726/MP2L2/PCM/AAC

Frame Rate

Main Stream:2Mbps / Sub Stream: 32Kbps

Lighting Specification

Night Vision Mode

Black&white mode

Number of infrared light

2 pcs

IR Distance

8~10m(23ft)

IR On/Off Control

Auto/ Manual

Network and condition

Wireless Standard

IEEE 802.11 b/g/n

Wireless Frequency

2.412 GHz ~ 2.474 GHz

WiFi Encryption Protocol

WPA-PSK/WPA2-PSK, WPA/WPA2, WEP

Working Temperature

-10 ℃ ~50 ℃

Storage Temperature

-10 ℃ ~50 ℃

Working Humidity

95%(No condensation)

Tuya SDK Version

SDK:4.9.10

Basic Specification

Pairing Method

QR code, AP

Two-way Talk

Not support

Motion Detection

Support

WebRTC

Support

Area Monitoring Detection

No

Privacy Zones

No

Humanoid Filtering

No

WDR

No

Anti Flicker

No

IR CUT

Support

Anti theft

No

Tamper alarm

No

Sound Alarm

Support

Sound Detection

Support

Reset button

Reset button

Local Storage SD Slot

Micro SD Slot (up to 128GB)

Hot Swappable SD Card

No

Condition to trigger local storage

Motion detection

How long per recording local video

N/A

How Long can an 8G SD Card Store Video

2-3(D)

Condition to trigger cloud storage

Motion detection

Tuya Cloud Storage

Support

Privacy Mode

Support

Power LED Color

No

Power LED On/Off Control

No

Status Indicator LED Color

No

Product Status for different Status Indicator LED color

No

Alexa and Google Assistant

Support

Mechanical Specification

Housing Material

ABS

Housing

White

Hosing Flame Retardance

UL94 V-0 750 ℃  FIRE-PROOF

Ingress Protection(IP)

IP20

Product Specification

Product Dimension

L76xW72.5xH113(mm)

Net Weight

180(g)

Power Cable Length

1.2 meters (type C)

Certification

Approved Certification

CE FCC

Accessories

Instruction manual

Yes

Accessory Contents

Power adapter, Type C usb cable, user manual
