| Pagrindinis | |
| Rėmas | Metal material |
| Svoris be įpakavimo | 0.54 kg (1.19 lb) |
| Svoris su įpakavimo | 1.08 kg (2.38 lb) |
| Dydis | 217.6 mm × 27.6 mm × 108.5 mm (8.57'' × 1.09'' × 4.27'') |
| Darbo sąlygos (temperatūra) | 0 °C to 40 °C (32 °F to 104 °F) |
| Sandėliavimo sąlygos temperatūra | -40 °C to 85 °C (-40 °F to 185 °F) |
| Darbo sąlygos (drėgmė) | 5% to 95% (no condensation) |
| Santykinė drėgmė | 5% to 95% (no condensation) |
| Maitinimas | 54VDC, 1.2A |
| Installation Mode | Desk-Mounted,Wall-Mounted |
| Maks. energijos sunaudojimas | 65 W |
| Energijos sunaudojimas miego režime | 2.5 W |
| Surge Protection | 6 KV |
| Tinklo parametrai | |
| Prievadai | 8 × Gigabit PoE port,2 × Gigabit RJ45 port |
| MAC adresų lentelė | 4 K |
| Perjungimo talpa | 20 Gbps |
| Paketų persiuntimo greitis | 14.88 Mpps |
| Vidinė cache atmintis | 1.5 Mbits |
| PoE | |
| PoE standartas | IEEE 802.3af,IEEE 802.3at |
| PoE galios jungtis | End-span: 1/2(-), 3/6(+) |
| PoE prievadas | PoE: Ports 1 to 8 |
| Maks. PoE prievadų galia | 30 W |
| PoE disponuojama galia | 60 W |
| Programinės įrangos funkcijos | |
| Ilgo diapazono režimas | Ports 1 to 8: up to 300 m.Long range performance may vary depend on camera model or cable condition. |
| Prievado izoliacija | Ports 1 to 8: port isolation mode to improve network securityPorts in an isolation group cannot communicate with each other, but they can communicate with ports outside the isolation group. |
| PoE Watchdog | Ports 1 to 8: auto detect and restart the cameras that do not respond. |
| Nuorodų agregavimas | Link aggregation is used to aggregate multiple physical ports to form a logical port for load balancing, bandwidth expansion, and port protection.Support static link aggregation.Support 3 aggregation groups. |
| Loop Prevention | Loop prevention is used to prevent the switching network from forming loops, which will seriously affect network communication. Disabled by default.Support 802.1D STP.Suppport 802.1w RSTP. |
| VLAN | VLAN is used for network scale planning and network health improvement.Support 802.1Q.Configurable VLAN ID from 1-4094.Support Trunk, Access port mode.Support Max. 32 VLAN. |
| HPP | Support one-click activation and remote management via Hik-Partner Pro. Functions supported:1. Display the port rate.2. Display the port bandwidth utilization rate.3. Display the PoE power usage.4. Display topology information.5. Display the alarm status.6. Restart ports and devices.7. Enable port long-rage mode.8. Remotely upgrade the device. |
| System Maintenance | Support device management via web.Support DHCP Client. Enabled by default for dynamic assignment of management IP addresses.Support Super IP, which is a fixed IP address (10.180.190.200) for direct access.Support management via Hik-Central Pro.Support remote management via Hik-Partner Pro.Support cable detection. Abnormal open circuits and short circuits as well as network cable length can be detected.Supports 802.1ab LLDP for peer device discovery.Support port mirroring for fault locating. |
| Patvirtinimai | |
| EMC | CE-EMC (EN 55032: 2015+A11: 2020, EN IEC 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011+A1: 2014, EN 55035: 2017+A11: 2020) |
| Saugumas | CB (AMD1:2009, AMD2:2013, IEC 62368-1: 2014 (Second Edition), CE-LVD (EN 62368-1: 2014+A11: 2017) |
| Cheminis tyrimas | Reach (Regulation (EC) No.1907/2006),WEEE (2012/19/EU),CE-RoHS (2011/65/EU) |
