EZVIZ CS-HP7 telefonspynės komplektas (IR 5m), žema kaina

Lauko durų skambutis
Sensorius 1/2.7" ProgressiveScan CMOS (Supports low light sensitivity)
Lęšis 2.0 mm @ F2.2,viewingangle: 162° (Diagonal)
Day & Night IR-cut filter withauto-switching, 850 nm infrared light × 2 (max. 6m)
Maks. rezoliucija 2048 × 1296
DNR 2D / 3D DNR
Vaizdo suspaudimas H.265 / H.264
Kadrų dažnis Max: 15fps; Self-Adaptiveduring network transmission

Ryšys ir funkcija
Prisijungimo būdas Wired connection (2-Wired,capable with 4-Wired), digital signal transmission
Perdavimo atstumas Φ 2 x 0.75mm² , max. 50m Φ2 x 1.5mm² , max. 100m Twisted pair, max. 120m
Durų atidarymas Support 2 wiring ports.1-10m distance. The intercom panel provides a “dry”-contact connection,without an electric current, to connect to the button for automatedgate, gate breaking capacity: 12V / 2A
Atrakinimas (elektrinė atrakinimo plokštė) Support 2 wiring ports.1-10m distance. The electric strike plate or lock that you order musthave a mechanical memory; the power supply to the electric strike plateor lock must not exceed 12V / 1.1A, otherwise should do as usermanual.
Durų atidarymo metodai 1.RFID badge unlock (Badges× 3 pcs) 2.App remote unlock 3.Indoor display unlock

Lauko durų skambučio sąsaja
Garso įvestis Built-in high-sensitivitymicrophone
Garso išvestis Built-in high-powerspeaker
Durų skambučio mygtukas Yes. The light can be seton or off.
Vardo kortelė Three handwritten namecards in total (one already on the intercom panel). The light can beset on or off.
Terminalas Two wiring ports to connectscreen. Two wiring ports to connect gate. Two wiring ports to connectelectric strike plate.

Sąsaja
Garso įvestis Built-in high-sensitivitymicrophone
Garso išvestis Built-in high-powerspeaker
Mygtukas Screen On / Off Button
Terminalas Two wiring ports to connect1st outdoor doorbell. Two wiring ports to connect 2nd outdoor doorbell.Two wiring ports to connect extra interior screen (not included in thekit)
Saugykla Supports microSD card up to512 GB Supports EZVIZ Cloud storage

Dėžutėje
Dėžutėje - Monitor- Wall Bracket forMonitor- Power Adapter forMonitor- Drill Template forMonitor- Intercom Panel- Drill Template forIntercom Panel- Screwdriver- Badges (×3)- Screw Kit (×2)- Name Card (×2)- Wires and WireConnectors- Regulatory Information(×2)- Quick Start Guide
