| Pagrindinis | |
| Rėmas | Metal material |
| Svoris be įpakavimo | 2.85 kg (6.28 lb) |
| Svoris su įpakavimo | 3.05 kg (6.72 lb) |
| Dydis | 440.0 mm × 220.8 mm × 44.0 mm (17.32'' × 8.69'' × 1.73'') |
| Darbo sąlygos (temperatūra) | 0 °C to 45 °C (32 °F to 113 °F) |
| Sandėliavimo sąlygos temperatūra | -40 °C to 85 °C (-40 °F to 185 °F) |
| Darbo sąlygos (drėgmė) | 5% to 95% (no condensation) |
| Santykinė drėgmė | 5% to 95% (no condensation) |
| Maitinimas | 100~240 V AC, 50/60 Hz, Max. 4 A |
| Installation Mode | Rack (equipped with mounting ears) |
| Maks. energijos sunaudojimas | 250 W |
| Energijos sunaudojimas miego režime | 20 W |
| Surge Protection | 6 KV |
| Tinklo parametrai | |
| Prievadai | 16 × Gigabit PoE port,1 × Gigabit RJ45 port,1 × Gigabit fiber optical port |
| MAC adresų lentelė | 8 K |
| Perjungimo talpa | 56 Gbps |
| Paketų persiuntimo greitis | 41.66 Mpps |
| Vidinė cache atmintis | 4.1 Mbits |
| PoE | |
| PoE standartas | IEEE 802.3af,IEEE 802.3at |
| PoE galios jungtis | 8-pin power: 1/2(-), 3/6(+), 4/5(+), 7/8(-) |
| PoE prievadas | PoE: Ports 1 to 16 |
| Maks. PoE prievadų galia | 30 W |
| PoE disponuojama galia | 230 W |
| Programinės įrangos funkcijos | |
| Ilgo diapazono režimas | Ports 1 to 16: up to 300 m. Long range performance may vary depend on camera model or cable condition. |
| Prievado izoliacija | Ports 1 to 16: port isolation mode to improve network security.Ports in an isolation group cannot communicate with each other, but they can communicate with ports outside the isolation group. |
| PoE Watchdog | Ports 1 to 16: auto detect and restart the cameras that do not respond. |
| Nuorodų agregavimas | Link aggregation is used to aggregate multiple physical ports to form a logical port for load balancing, bandwidth expansion, and port protection.Support static link aggregation.Support 8 aggregation group(s). |
| Loop Prevention | Loop prevention is used to prevent the switching network from forming loops, which will seriously affect network communication. Disabled by default.Support 802.1D STP.Suppport 802.1w RSTP. |
| VLAN | VLAN is used for network scale planning and network health improvement.Support 802.1Q.Configurable VLAN ID from 1-4094.Support Trunk, Access port mode.Support Max. 32 VLAN. |
| HPP | Support one-click activation and remote management via Hik-Partner Pro. Functions supported:1. Display the port rate.2. Display the port bandwidth utilization rate.3. Display the PoE power usage.4. Display topology information.5. Display the alarm status.6. Restart ports and devices.7. Enable port long-rage mode.8. Remotely upgrade the device. |
| System Maintenance | Support device management via web.Support DHCP Client. Enabled by default for dynamic assignment of management IP addresses.Support Super IP, which is a fixed IP address (10.180.190.200) for direct access.Support remote management via Hik-Partner Pro.Support cable detection. Abnormal open circuits and short circuits as well as network cable length can be detected.Support 802.1ab LLDP for peer device discovery.Support port mirroring for fault locating. |
| Patvirtinimai | |
| EMC | CE-EMC (EN 55032: 2015, EN IEC 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011 +A1: 2014, EN 55035: 2017) |
| Saugumas | CB (IEC 60950-1:2005, AMD1:2009, AMD2:2013, IEC 62368-1: 2014 (Second Edition); CE-LVD (EN 60950-1: 2006 + A11: 2009 +A1: 2010+A12: 2011+A2: 2013, EN 62368-1: 2014+A11: 2017) |
| Cheminis tyrimas | CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No.1907/2006) |
