| Maitinimas | |
| Maitinimo įtampa | 110–230 V ± 10%, 50/60 Hz |
| Maksimali pastovi apkrovos srovė | 13 A |
| Išvesties galia | up to 3.0 kW (resistive load at 230 V~), up to 1.5 kW (resistive load at 110 V~) |
| Vidutinės sąnaudos | up to 1 W |
| Srovės apsauga | more than 11 A (when Overcurrent protection is enabled), more than 13 A (when Overcurrent protection is disabled), Once the current exceeds the specified level, the device turns off automatically. |
| Įtampos apsauga 230 V~ elektros tinklui | min: 184 V~, max: 253 V~, Once the voltage exceeds the specified levels, the device turns off automatically. |
| Įtampos apsauga 110 V~ elektros tinklui | min: 92 V~, max: 132 V~, Once the voltage exceeds the specified levels, the device turns off automatically. |
| Temperatūros apsauga | over 149 °F, If protection is triggered, the device turns off. |
| Apsaugos nuo elektros smūgio klasė | Class II |
| Bendravimas | |
| Jeweller ryšio technologija | Proprietary wireless communication technology to transmit commands, alarms, and events., Key features:, Two-way communication., Advanced anti-sabotage., Block encryption featuring a dynamic key., Instant notifications., Remote control and configuration in Ajax apps., Learn more |
| Dažnių juostos | 866.0–866.5 MHz 868.0–868.6 MHz 868.7–869.2 MHz 905.0–926.5 MHz 915.85–926.5 MHz 921.0–922.0 MHz, Depends on the sales region. |
| Maksimali efektyvi spinduliuojama galia (ERP) | up to 25 mW |
| Radijo signalo moduliacija | GFSK |
| Radijo ryšio veikimo nuotolis | up to 3,250 ft, Between the relay and a hub (or a range extender) in an open space., Calculate radio communication range at the facility |
| Šifruotas ryšys | All stored and transmitted data are protected by block encryption featuring a dynamic key. |
| Dažnių šuoliai | To prevent radio interference and jamming., Learn more |
| Pagrindinės savybės | |
| Valdymas per išmanųjį telefoną | The user can set up the relay configurations and receive notifications in an Ajax app. |
| Automatizavimo scenarijai | By arming/disarming, By schedule, By alarm, By temperature, By humidity 1, By CO 2 concentration 1, By touching LightSwitch / pressing Button, Learn more, 1 Scenarios by humidity and CO 2 concentrations are available when LifeQuality Jeweller is added to the system. |
| Energijos sąnaudų stebėjimo priemonė | Control of the current, voltage, power, and electric energy consumed by connected appliances. |
| Adjustable pulse duration 2 | from 1 to 255 s |
| Veikimo režimai | pulse 2, bistable, 2 Available on devices with firmware version 5.54.1.0 or later manufactured after March 5, 2020. |
| Kontakto būsena | normally open, normally closed |
| Apsauga nuo sabotažo | |
| Apsauga nuo klastojimo | device authentication |
| Ryšio praradimo aptikimas | after 36 s, Detection time depends on the Jeweller or Jeweller/Fibra settings., Learn more |
| Korpusas | |
| Matmenys | 1.54″ × 1.3″ × 0.71″ |
| Svoris | 1.06 oz |
| Darbinė temperatūros riba | from 32 °F to 147 °F |
| Drėgmė | up to 75% with no condensation |
| Apsaugos klasė | IP20 |
