Hikvision HeatPro serijos...

Garsinis ir vaizdinis signalas
Garso signalizacija Yes, for two types of audible alarm (VCA and Temperature Exception)2 preset voice alerts (one for each)6 importable user-defined voice alerts (6 options shared in the two types)
Vaizdinė signalizacija Yes. White light alarm with adjustable flashing frequencies
Baltos šviesos diapazonas Up to 30 m

Bendrieji duomenys
Matmenys 321.3 mm × 106.1 mm × 107.0 mm (12.65" × 4.18" × 4.21")
Energijos sąnaudos 24 VAC ± 25%: 0.8 A, Max.8.5 W12 VDC ± 25%: 0.7 A, Max.8.5 WPoE (802.3af, class 3): 36 V to 57 V, 0.24 A to 0.15 A, Max. 8.5 W
Maitinimo šaltinis 24 VAC ± 25%, 12 VDC ± 25%, two-core terminal blockPoE (802.3af, class 3)
Apsaugos lygis IP67 Standard TVS 6000V lightning protection, surge protection, voltage transient protectionIK10-rated housing
Tinklo naršyklės kalba 32 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil)
Svoris 1550 g (3.41 lb)
Darbinė temperatūra / drėgmė Temperature: -40°C to 65°C (-40°F to 149°F) Humidity: 95% or less

Sąsaja
Alarm Action SD recording/Relay output/Smart capture/FTP upload/Email linkage
Signalizacijos įvestis 2, alarm input (0-5 VDC)
Signalizacijos išvestis 2, alarm output (alarm response actions configurable)
Analoginė išvestis 1.0V [p-p]/75Ω, PAL/NTSC/BNC
Garso įvestis 1, 3.5 mm Mic in/Line in interfaceLine input: 2 to 2.4 V [p-p], output impedance: 1 KΩ ± 10%
Garso išvestis Linear level, impedance: 600 Ω
Bendravimo sąsaja 1, RJ45 10 M/100 M Self-adaptive Ethernet interface.1, RS-485 interface (half duplex)

Tinklas
API ISAPI, HIKVISION SDK,ISUP, and third-party management platform, Open Network Video Interface,ONVIF (Profile S, Profile G)
Klientas iVMS-4200, Hik-Connect
Vidinė atmintis MicroSD/SDHC/SDXC card (up to 256 G) local storage, NAS (NFS, SMB/CIFS), Auto Network Replenishment (ANR)
Protokolai IPv4/IPv6,HTTP,HTTPS,802.1x,Qos,FTP,SMTP,UPnP,SNMP,DNS,DDNS,NTP,RTSP,RTCP,RTP,TCP,UDP,IGMP,ICMP,DHCP,PPPoE,Bonjour,SFTP,SRTP,TLS
Saugumas User authentication (ID and Password), MAC address binding, HTTPS encryption, IEEE 802.1x(EAP-MD5, EAP-TLS), access control, IP address filtering
Tiesioginis vaizdo žiūrėjimas Up to 20 channels
User/Host level Up to 32 users, 3 levels: Administrator, Operator, User
Naršyklė Live view (plug-in allowed) : Internet Explorer 11Live view (plug-in free) : Chrome 57.0 +, Firefox 52.0 +Local service : Chrome 57.0 +, Firefox 52.0 +

Išmanioji funkcija
Pagrindinės funkcijos Fire detection, smoking detection, sun-reflection filter
Temperatūros tikslumas ± 8°C (± 14.4°F)
Temperatūros matavimas 3 temperature measurement rule types, 21 rules in total (10 points, 10 areas, and 1 line)
Temperatūros diapazonas -20°C to 150°C (-4°F to 302°F)
VCA 4 VCA rule types (line crossing, intrusion, region entrance, and region exiting), up to 8 VCA rules in total.

Vaizdas ir garsas
Garso glaudinimas G.722.1/G.711ulaw/G.711alaw/MP2L2/G.726/PCM
Pagrindinis srautas Thermal:25 fps (1280 × 720, 704 × 576, 640 × 512, 320 × 240)Optical:50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)60Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
Antrinis srautas Thermal: 25 fps (704 × 576, 640 × 512, 320 × 240)Optical:50 Hz: 25 fps (704 × 576, 352 × 288)60 Hz: 30 fps (704 × 480, 352 × 240)
Vaizdo glaudinimas Main Stream: H.265/H.264Sub-Stream: H.265/H.264/MJPEG
