ColorWay CW-CHS055PD-WT
Compact and powerful GaN charger supporting all modern fast charging protocols.
The ColorWay CW-CHS055PD-WT is a modern solution for fast charging of your devices. With two ports (USB-C and USB), it allows simultaneous charging of two devices with a total power of up to 35 W. The charger supports advanced fast charging technologies including PD 3.0 PPS, Quick Charge 3.0/4.0+ and many other manufacturer-specific protocols.
The adapter uses advanced GaN technology, making it lighter, smaller and more efficient than traditional chargers. It produces minimal heat during operation, consumes less power, and significantly speeds up device charging. The intelligent USB Auto ID chip automatically detects the connected device and adjusts the voltage and current up to 3A to ensure maximum charging efficiency.
Two charging ports - USB-C (PD) and USB (QC) for simultaneous charging of two devices
Maximum power of 35 W for USB-C port and 18 W for USB port
Support for all modern fast charging protocols (PD 3.0, PPS, QC3.0/4.0+)
Intelligent Auto-ID chip for automatic detection of optimal charging current
Compact dimensions of 78 × 34 × 32 mm and low weight of only 57 g
GaN technology for higher efficiency and lower heating
Multi-level protection system against short circuit, overheating and overvoltage
Made of non-flammable, scratch- and impact-resistant ABS plastic
BASIC SPECIFICATIONS
Maximum current: 3 A
Input: AC 100-240 V, 50-60 Hz, 1 A Max.
USB-C Output: DC 5V/3A, 9V/3A, 12V/2.91A, 15V/2.33A, 20V/1.75A, PPS 3.3-11V/3A, 35 W Max
USB Output: DC 5V/3A, 9V/2A, 12V/1.5A, 18 W Max
Combined output: 5V/3.6A, 18 W
Dimensions: 78 × 34 × 32 mm
Weight: 57 g
Supported protocols: PD 3.0, PPS, BC1.2 DCP, Apple Fast charge, Xiaomi Turbo Charge, Samsung AFC/SFC, QC2.0/3.0/4.0+, HUAWEI FCP/SCP
