Name: Šakotuvas 6 prievadų, 4 PoE komutatorius UTP6306S-PSB
SKU: 45024004
Price: 198.37 EUR
Availability: InStock

4*10/100/1000 Base-T PoE RJ-45 prievadai
2*1000 Base-X SFP prievadų
1*RJ-45 konsolės prievadas
Darbinė temperatūra: -40 ℃ ~ 75 ℃
Perteklinis maitinimo šaltinis
8kV kontaktinis išlydis, 12kV oro iškrovimas ESD apsauga
Metalinio korpuso dizainas be ventiliatoriaus
DIN bėgelio montavimas

Pagrindinis
Įrenginys	UTP3306TS-PSD
Downlink prievadai	4*10/100/1000 Base-T PoE++ RJ-45(Auto-MDI/MDI-X)
Uplink prievadai	110/100/1000 Base-T RJ-4511000 Base-X SFP
Led indikatoriai	1PWR, power supply indicators1Link/Act, SFP port state indicators
Dydis	294mm180mm44mm
Įeinanti įtampa	100~240V AC, 50~60Hz
Energijos sunaudojimas	≤370W (Full load including PoE)
Medžiaga	Metal shell
Montavimas	Rack/Desktop/Wall mounted
Standartai	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1D, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt
Persiuntimo režimai	Store and Forward
MAC adresų lentelė	2k, support auto learning
Perjungimo talpa	12Gbps/non-blocking
Paketų persiuntimo greitis	8.928Mpps
Port Buffer	1MB
Jumbo Frame	9716 Bytes
PoE standartas	IEEE 802.3af/at/bt
PoE maitinimo tipas	End-span
PoE išdėstymas	3/6/4/5(+), 1/2/7/8(-)
PoE biudžetas	90W max for each port, 360W max for whole switch
Darbo sąlygos temepratūra	-10℃~50℃, 5%~95% (Non-condensation)
Saugykla	-40℃~70℃, 5%~95% (Non-condensation)
Sertifikatai	CE, FCC
Sistemos informacija	System, Hardware, Time and Firmware
IP būsena	IP Interfaces, IP Routes and ARP Table
Sistemos pranešimai	System Log Information
Detalūs sistemos pranešimai	ID and Message
MAC adresų lentelė	MAC Address Table: Type, VLAN, MAC Address, CPU and Port Number
VLANs	Membership and Ports
Prievadai	Traﬃc Overview and Detailed Statistics
LACP	System Status, Port Status and Port Statistics
Apsauga nuo perkaitimo	Thermal Protection Port Status
Green Ethernet	Port Power Savings Status
PoE statusas	Power Over Ethernet Status
LLDP	Thermal Protection Port Status
Loop Protection	Loop Protection Status
Aprėpiantys protokolai	Bridge Status, Port Status and Port Statistics
IGMP Snooping	IGMP Snooping Status, Groups Information and IPv4 SFM Information
MLD Snooping	MLD Snooping Status, Groups Information and IPv6 SFM Information
DHCP	Server, Snooping Table, Relay Statistics and Detailed Statistics
Saugumas	Port Security, Access Management Statistics, 802.1X, ACL Status and AAA
QoS	QoS Statistics and QCL Status
IP Conﬁg	IP Conﬁguration, IP Interfaces and IP Routes
IP būsena	IP Interfaces, IP Routes and ARP Table
DHCP serveris	DHCP Server Mode Conﬁguration, Excluded IP and Pool
NTP	NTP Conﬁguration
Timezone	System Timezone Oﬀset and UTC time
SNMP	System, Trap, Communities, Users, Groups, Views and Access
Sistemos pranešimai	System Log Conﬁguration
Prievadai	Port Conﬁguration
Aggregation	Static and LACP
Mirroring	Mirror and Mirror Port Conﬁguration
Apsauga nuo perkaitimo	Thermal Protection Conﬁguration
Green Ethernet	Port Power Savings and Port Conﬁguration
DDM	DDM Conﬁguration, DDM Overview and DDM Detailed
PoE nuostatai	Power Over Ethernet, PoE Power Supply and PoE Port Conﬁguration
PoE statusas	Power Over Ethernet Status
MAC adresų lentelė	Aging Conﬁguration, MAC Table Learning and Static MAC Table Conﬁguration
PTP	PTP Clock Conﬁguration and PTP Status
VLANs	Global VLAN and Port VLAN Conﬁguration
Balso VLAN	Voice VLAN Conﬁguration and Voice VLAN OUI Table
GVRP	GVRP Global and Port Conﬁguration
Prievado izoliacija	Port Group and Port Isolation
Loop Protection	General Settings and Port Conﬁguration
Aprėpiantys protokolai	Bridge Settings, MSTI Mapping, MSTI Priorities, CIST Ports and MSTI Ports
IPMC profilis	Proﬁle Table and Address Entry
MEP	Maintenance Entity Point
ERPS	Ethernet Rapid Ring Protection Switching
IGMP Snooping	Basic Conﬁguration, VLAN Conﬁguration and Port Filtering Proﬁle
IPV6 MLD Snooping	Basic Conﬁguration, VLAN Conﬁguration and Port Filtering Proﬁle
LLDP	LLDP Parameters and LLDP Interface Conﬁguration
Vartotojai	Users Conﬁguration
Privilegijų lygiai	Privilege Level Conﬁguration
SSH	SSH Conﬁguration
HTTPS	HTTPS Conﬁguration
Prievado saugumo riba	System and Port Conﬁguration
Prieigos valdymas	Access Management Conﬁguration
802.1X	Network Access Server Conﬁguration
ACL	Ports, Rate Limiters and Access Control List
ARP Inspection	Port Conﬁguration, VLAN Conﬁguration, Static Table and Dynamic TableAAA RADIUS and TACACS+
Port Classiﬁcation	QoS Ingress Port Classiﬁcation
Prievado politika	QoS Ingress Port Policers
Eilės politika	QoS Ingress Queue Policers
Prievado planavimas	QoS Egress Port Schedulers
Prievado formavimas (port shaping)	QoS Egress Port Shapers
Prievado žymos žymėjimas	QoS Egress Port Tag Remarking
Prievado DSCP	QoS Port DSCP Conﬁguration
DSCP-Based QoS	DSCP-Based QoS Ingress Classiﬁcation
DSCP vertimas	DSCP vertimas
DSCP klasifikacija	DSCP klasifikacija
QoS valdymo sąrašas	QoS Control List Conﬁguration
Storm Policing	Global Storm Policer Conﬁguration
Ping	ICMP Ping
Kabelio diagnostika	Cable Status
Procesoriaus apkrova	CPU Load Information
Įrenginio paleidimas iš naujon	Restart the Device
Gamykliniai nustatymai	Gamykliniai nustatymai
Programinės įrangos atnaujinimas	Software Upload
Programinės įrangos pasirinkimas	Software Image Selection
Konfigūracija	Download, Upload, Activate and Delete
