Goobay SAT prioriteto jungiklis –...


Modelio pavadinimas	51445
Gamintojo prekės serija	Sat priority switch - distributes 1 lnb to 2 sat receivers
Techniniai duomenys
Kitos savybės	• connection of 2 sat receiver at 1 coax cable (master/slave connection) • master output: receiver (1) connected and control lnb output / program switching • slave output: receiver (2) connected and control lnb output/program switching only, if the receiver (1) is switched off / standby • receiver off/standby is defined by no dc • control signal is 13 v / 18 v, 22 khz on/off, diseqc from receiver 1/2 • frequency range: 950 mhz ~ 2400 mhz • decoupled diodes
Kitos funkcijos
Techniniai parametrai	Distributes 1 lnb to 2 sat receivers connection of 2 sat receiver at 1 coax cable (master/slave connection) master output: receiver (1) connected and control lnb output / program switching slave output: receiver (2) connected and control lnb output/program switching only, if the receiver (1) is switched off / standby receiver off/standby is defined by no dc control signal is 13 v / 18 v, 22 khz on/off, diseqc from receiver 1/2 frequency range: 950 mhz ~ 2400 mhz decoupled diodes
Savybės
Gaminio spalva	Sidabrinė

Modelio pavadinimas	51445

Goobay SAT prioriteto jungiklis – paskirsto 1 LNB 2 SAT imtuvams 51445
