Phanteks XT V3 PC Case, Mini Case,...

Micro-ATX case, innovative power supply mounting at the front, GPU up to 430mm, space for up to seven 120mm fans, separate radiator chamber, glass panels on the front and side, including three 120mm reverse fans

The Phanteks XT V3 combines a compact design with plenty of room for modern hardware. With stylish glass panels and strong cooling, your gaming setup becomes a true showcase.

Compact Micro-ATX case: ideal for modern builds
Plenty of space: supports GPUs up to 430mm in length
Optimized for cooling: up to seven 120mm fans or a 360mm radiator
Compatible: with back-connect motherboards
Showcase design: tempered glass panels on the front and side

The Phanteks XT V3: Compact Mini Case with Ample Space

Thanks to its compact form factor, the Phanteks XT V3 can be easily integrated into a wide range of gaming or professional setups – while still offering excellent support for modern hardware. The spacious interior accommodates Mini-ITX and Micro-ATX motherboards and supports back-connect designs . High-performance GPUs also fit with ease, as the Phanteks XT V3 provides four PCIe slots and clearance for GPUs up to 430 mm .

The rear chamber of the case also impresses with an innovative design for premium hardware. Instead of the usual position, the PSU has been relocated to the top front. This allows the Phanteks XT V3 to support full-sized ATX power supplies, delivering greater compatibility.

Powerful Cooling

The Phanteks XT V3 delivers outstanding cooling performance. Seven mounting points for 120 mm fans – three at the top, three at the bottom, and one at the rear – enable efficient airflow layouts. Out of the box, three powerful M25-120 reverse DRGB fans at the base provide excellent cooling. In addition, the Phanteks XT V3 features a dedicated chamber at the top for a 360mm radiator. This makes it easy to install a high-performance AIO cooler, keeping even high-end CPUs reliably cool during intense gaming sessions.

Showcase Case

With the Phanteks XT V3 , you can perfectly showcase both your hardware and your building skills. The rear chamber offers generous space for cable management along with smart routing options for a clean system. Completing the look are tempered glass panels on the front and side, providing an unobstructed view of your components from any angle.

Comprehensive I/O Panel

The Phanteks XT V3 provides excellent support for your gaming setup thanks to the front I/O panel on the bottom right. It features both a USB Type-A and Type-C port with USB 3.2 Gen 2x2 standard. In addition, a 3.5mm combo audio jack is available for your gaming headset.

Specification

Colour
Primary Colour	White
Dimensions
Length / Depth	460 mm
Width	235 mm
Height	370 mm
Weight	6.05 kg
Case
Case Type	Mini Case
Motherboard Support
Compatible Motherboard Formats	Micro-ATX, Mini-ITX
Max. Motherboard Format	Micro-ATX
Internal Dimensions
Max. CPU Cooler Height	175 mm
Max. GPU Length	430 mm
Max. GPU Width	175 mm
Max. PSU Length / Depth	150 mm
Display
Display Included	No
Power Supply
PSU included	No
PSU Format	ATX
Power Supply Position	front
Cable Specifications
Riser Cable Included	No
Fan Support
Max. Number of Fans	7
120 mm fans	7
Radiator Support
Max. Radiator Compatibility	1x Triple (360 mm)
Drive Bays
Max. 2.5 Inch Drives	2
Max. 3.5 Inch Drives	1
Max. 5.25 Inch Drives	0
Hot swap drive bays	No
External Ports
USB4 Gen 2x2 (external) Type C	1
USB 3.0 (external) Type A	1
Audio outputs & inputs	1x output / input comb. (3.5 mm jack, 4-pin, TRRS)
Card reader	No
Case Features
I/O position	Front
Side panel	with window
Vertical GPU Mount	No
Adjustable Vertical GPU Bracket	No
Front door	No
Cable Management	Yes
Filters Included	No
Noise dampening	No
Mainboard slide / tray	No
Transport System	No
Back Connect
Back Connect	Yes
Expansion Slots
Expansion slots / PCI slots	4
Features
Housing Feedthrough	No
Fan Header
Fan Controller / Fan Hub	No
Mounting
Case VESA Mountable	No
Internal Monitor Mount	No
Materials
Materials	ABS, Steel, Tempered Glass
Lighting
Lighting / RGB	Yes
RGB Controller	No
Additional Contents
Included fans	3x 120 mm
