Makera Carvera 4th Axis Module – Harmonic Drive Version

Expand your CNC capabilities with the Carvera 4th Axis Module, designed to bring true 4-axis simultaneous machining to your Carvera or Carvera Air machine. This harmonic-drive-based rotary axis allows you to create complex, multi-sided parts with precision, opening up possibilities for cylindrical, double-sided, and fully 3D-contoured designs. Key Features

• Enables true 4-axis simultaneous CNC machining
• Harmonic drive system ensures ultra-low backlash and high accuracy
• Supports wood, plastic, and non-ferrous metals
• The rotary axis offers a precision of 0.01 degrees and supports rotational speeds of up to 2400 degrees per minute.
• Work area of 92 mm 240 mm for a wide range of part sizes

Advanced Precision with Harmonic Drive

At the heart of this module is a harmonic drive, offering near-zero backlash and superior positioning accuracy compared to traditional gear systems. This makes it ideal for intricate work where detail and repeatability matter.

Seamless Integration

Designed exclusively for the Carvera and Carvera Air CNC machines, the 4th Axis Module integrates easily into your existing setup. Installation is simple thanks to included mounting accessories and step-by-step instructions.

Powerful and Versatile

Equipped with a high-performance NEMA 17 stepper motor, the rotary axis reaches speeds up to 2400 degrees per minute while maintaining a fine resolution of 0.01 degrees. The module handles a variety of materials including wood, plastics, and non-ferrous metals, allowing for creative flexibility.

CAM Software Compatibility

The module is fully supported by MakeraCAM for straightforward 4-axis programming. It also integrates with advanced software such as Fusion 360 and VCarve, giving experienced users the freedom to create custom toolpaths for more demanding projects.
